Rolling Tool Box with Telescopic Gas Spring Columns | GARANT
Built for mobile tool storage on the shop floor, this GARANT rolling tool box opens telescopically from a closed height of 520 mm (20.5 in.) to a working height of 935 mm (36.8 in.). Two columns rise with gas spring support, so the top section lifts smoothly even when the box is fully loaded. It rolls between workstations, service bays, and garage benches as a compact tool trolley.
The body is deep-drawn sheet metal, giving this roller tool box a stable base container, two storage trays, and a cover with all-round protective edging and an X-ABS mat. When you close it, the telescopic columns slide into each other so nothing projects from the closed unit. A two-tone powder coating pairs silver panels with RAL 7016 anthracite.
Key features:
• Gas pressure springs: each telescopic column carries an integral spring with 20 kg (44.1 lb) of force, assisting opening and closing under load.
• Central locking: one cylinder lock with a modular barrel secures the whole mobile tool cabinet.
• Roller bearing wheels: two castors with parking brake and two fixed wheels give controlled moves and steady parking.
• Fold-away handle: pulls out for pushing and pulling, then folds away when the cart is parked.
Which mobile tool storage works when bench space is tight?
A telescopic tool box answers tight floor plans, opening to working height at the bench and closing low to roll clear of walkways.
Applications: mobile tool storage, tool transport between workstations, machine maintenance rounds, assembly work, garage projects, secure overnight tool keeping.
Industries: machining, automotive service, general manufacturing, facility maintenance.
Users: machinists, maintenance technicians, automotive mechanics, shop supervisors.
How do the supplied partitions divide up the base container?
The supplied dividing material includes six divider partitions at 365 mm (14.4 in.), one at 435 mm (17.1 in.), and one partition for the base tray, so you can split the deep container into zones for hand tools, accessories, and consumables. Group tools by task and size within each zone. Daily-use items ride in the two storage trays, and the base is reserved for bulkier equipment.
What are the usable storage dimensions inside this tool cart?
Inside, the storage compartment gives you a usable depth of 330 mm (13.0 in.) front to back. Storage shelf height is 60 mm (2.36 in.), so check taller items against that clearance before you decide where they travel. The overall footprint is 670 mm (26.4 in.) wide by 365 mm (14.4 in.) deep, compact enough to park beside a workbench without crowding the aisle.
Is this a heavy duty rolling tool box for daily shop use?
Yes, this GARANT tool cart is built to take daily professional shop duty. Its deep-drawn sheet metal body carries heavy tool loads without flexing, and what keeps a heavy duty rolling tool box moving is attention to the running gear, so wipe the exterior down as routine care and keep the wheels clear of chips to preserve smooth movement. Those two habits are all a rolling tool cart asks of you.
Warning:
- For mobile work on site.
- For both industrial and private use.
- Storage trays for storage of tools.
- Storage shelf for storage of workpieces and tools.
- Use exclusively approved Hoffmann Group accessories for modification or rebuilding.
- Do not stand or sit on the roller cabinet. Do not carry people.
- Do not make any unauthorised modifications.
- Do not expose the roller cabinet to impacts.
