Description
Version:
For use of mechanical and digital branded torque wrenches (not HCT) and screwdrivers, and setting and checking triggering, indicating, right-hand and left-hand turning torque wrenches and screwdrivers.
Units of measurement: Nm, lbfft, lbfin.
Function:
IP40: Protected against penetration by foreign bodies with ? > 1 mm. However, tools and wires should be kept away and there is no protection against water.
Accuracy:
Clockwise and anti-clockwise: +/- 1%.
Supplied with:
USB-C data cable (1.8 m), power supply unit, country adapter (types A, C, G and I), certificate of conformity. Supplied in a sturdy plastic case.
Note:
Suitable additional adapters can be found under No. 649550 and No. 650006.
Calibration: O4
Torque measuring accuracy: ± 1 %
IP Index of Protection: IP 40
Resolution: 1 Nm
Measuring range: 100 - 1000 Nm
Display unit width: 171 mm
Display unit height: 86 mm
Display unit depth: 161 mm
Weight: 3.3 kg
For use of mechanical and digital branded torque wrenches (not HCT) and screwdrivers, and setting and checking triggering, indicating, right-hand and left-hand turning torque wrenches and screwdrivers.
- Display: Large sharp contrast illuminated 2.8 inch TFT display with double scale with viewing angle stability. With memory capacity display.
- Memory capacity: 1000 measurement values with time stamp (incl. date and time) and 20 configurable test cases.
- Modes: Tracking display (Track), trigger point sensing (First-Peak) and peak value display (Peak Hold).
- Attachment: can be attached to flat surfaces (table, wall, etc.) using 4 screws (M10).
- 3 recesses for secure storage of adapters (increaser piece).
- Data output: Available via USB-C. The data can the exported as a .csv file.
- Password protection: available as protection against unauthorised access to the menu (master password) and for verifying test cases. In addition, you can set that reworking a test case that has been performed incorrectly requires input of a password.
- Warning signals: visual (change of colour on the display) and acoustic (buzzer). The pre-warning point can be configured individually. The acoustic warning signal can be disabled if desired.
- Protection class IP40
- Languages: German, English, Spanish, Italian, French.
- Factory settings: Can be reset to the factory settings.
- Displays the software version with the serial number and date of the last calibration. The date of the next calibration can be set on the torque analyser.
